Allied Machine & Engineering
OP3-1L-HSK100
Opening Drill Holder
Specifications
| Drill Depth (Inch) | 9-7/64 |
|---|---|
| Through Coolant | Yes |
| Shank Type | HSK 100 |
| Unit Of Measure | Fractional |
| Series | OP3 |
| Length (Decimal) | 14.86 |
| Height (Decimal) | 9.57 |
| Width (Decimal) | 9.57 |
| Coolant Inlet Style Rear | Through The Shank |
| Gage Length (Fractional) | 11-31/32 |
| Length Type | Long |
| Maximum Diameter (Decimal) | 4.12 |
| Minimum Diameter (Decimal) | 3 |
| Number Of Inserts | 4 |
| Base Item Number | OP3-1L-HSK100 |
| Flute Type | Straight |
| Product Type | Industrial Supplies |
| Unit of Measure | Fractional |
| Coolant | Yes |
| Width | 9.57 |
| Minimum Diameter (Inch) | 3 |
| Length | 14.86 |
| Gage Length (Inch) | 11-31/32 |
| Country of Origin | US |
