Apex
GL70203AKY
Diagonal Pliers 7"
Specifications
| ANSI Specification | ANSI B107.11M |
|---|---|
| Base Item Number | GL70203AKY |
| Blade Length | 21 mm |
| Cutting Capacity | Copper Wire φ2.6 mm, Iron Wire φ2.4 mm, Hard Wire φ2.0 mm |
| Jaw Length | 33 mm |
| Jaw Thickness | 13.8 mm |
| Jaw Width | 30 mm |
| Overall Length | 18.7 cm |
| Overall Width | 5.7 cm |
| Short Description | Diagonal Pliers 7" |
| Size | 7" |
| Weight (Catalog) | 11.8 kg |
| Overall Height | 2.4 cm |
| DIN Specifications | DIN 5238 |
