Apex
SC70302A
Combination Pliers
Specifications
| ANSI Specification | ANSI B107.13M |
|---|---|
| Base Item Number | SC70302A |
| Blade Length | 16 mm |
| Cutting Capacity | Copper Wire φ2.6 mm, Iron Wire φ2.4 mm, Hard Wire φ2.0 mm |
| Jaw Length | 47.5 mm |
| Jaw Thickness | 10.5 mm |
| Jaw Width | 25 mm |
| Overall Length | 17.7 cm |
| Overall Width | 5.5 cm |
| Short Description | Combination Pliers |
| Size | 7" |
| Weight (Catalog) | 11.4 kg |
| Overall Height | 2.4 cm |
| DIN Specifications | DIN 5236 |
