Apex
SC72302A
Extreme Leverage Diagonal Pliers
Specifications
| ANSI Specification | ANSI B107.11M |
|---|---|
| Base Item Number | SC72302A |
| Blade Length | 25 mm |
| Cutting Capacity | Copper Wire φ2.6 mm, Iron Wire φ2.4 mm, Hard Wire φ2.0 mm |
| Jaw Length | 33.5 mm |
| Jaw Thickness | 12.6 mm |
| Jaw Width | 24 mm |
| Overall Length | 17.7 cm |
| Overall Width | 2.4 cm |
| Short Description | Extreme Leverage Diagonal Pliers |
| Size | 7" |
| Weight (Catalog) | 11.5 kg |
| Overall Height | 1.26 cm |
| Jaw Opening | 15 mm |
| DIN Specifications | DIN 5238 |
