Balax
40076-01C
10-32 BH6 45?SPFL Thredshaver
Specifications
| Thread Limit | H6 |
|---|---|
| Coating/Finish | TiCN |
| Thread Size | 10-32 |
| Chamfer | 2.5 |
| Overall Length | 2-3/8" |
| Tap Style | Spiral Flute |
| Thread Type | UNF |
| Shank Diameter | 0.194" |
| Thread Length | 0.360" |
| Neck Length | 7/8" |
| Square | 0.152" |
| Chamfer Style | Modified Bottom |
| Square Size | 0.152" |
| Square Length | 1/4" |
