Carmex
CPGW060204NCVD
Carmex CPGW060204NCVD
Specifications
| Short Description | CPGW 060204 N CVD |
|---|---|
| Type | Neutral |
| Material | Carbide |
| Function | Turning |
| Has Hole | Y |
| Radius (Inch) | (1/64) in |
| EIRL | External Right-Hand;External Left-Hand;Internal Right-Hand;Internal Left-Hand |
| Is Coated | Y |
| Holder Code | SCLP…06;A…SCUP…06 |
| Thickness (Inch) | (3/32) in |
| Insert Shape | 80° Diamond |
| Thickness (Metric) | 2.38 mm |
| Radius (Metric) | 0.4 mm |
| Grade | CVD |
| Has Chipbreaker | N |
| Relief Angle (Deg) | 11° |
| Hole Shape | 40° - 60° Double Countersink |
| Cutting Edge Material | Diamond |
| Cut Angle (Deg) | 80° |
| Country of Origin | DE |
