Carmex
MGR3B07L10BXC
Carmex MGR3B07L10BXC
Specifications
| Short Description | MGR 3 B0.7 L10 BXC |
|---|---|
| Shank Type | Cylindrical (Weldon) |
| Material | Carbide |
| Centerline to Cutting Edge (in) | 0.050 in |
| Function | Grooving |
| EIRL | Internal Right-Hand |
| Is Coated | Y |
| Holder Code | SIM…H3 |
| Shank Diameter (Inch) | 0.12 in |
| Grade | BXC |
| Has Coolant | Y |
| Coolant Type | Edge Bore |
| Centerline to Cutting Edge (Metric) | 1.30 mm |
| Country of Origin | IL |
| Overall Length (Inch) | 1.5 in |
