Carmex
MT1615E3714UNMT7
Carmex MT1615E3714UNMT7
Specifications
| Number Of Flutes | 5 |
|---|---|
| Overall Length (Inch) | 4.1 in |
| Short Description | MT 1615 E37 14 UN MT7 |
| Thread Standard | (7/8) |
| Material | Carbide |
| Shank Type | Cylindrical (DIN6535-HA) |
| Function | Threading |
| EIRL | Internal Right-Hand;Internal Left-Hand |
| Is Coated | Y |
| Shank Diameter (Inch) | 0.63 in |
| Thread Form | UN |
| Grade | MT7 |
| Pitch (TPI) | 14.00 TPI |
| Has Coolant | N |
| Cut Diameter (Inch) | 0.591 in |
| Country of Origin | IL |
