Carmex
MTB1009D2612WMT7
Carmex MTB1009D2612WMT7
Specifications
| Number Of Flutes | 4 |
|---|---|
| Overall Length (Inch) | 2.9 in |
| Short Description | MTB 1009 D26 12 W MT7 |
| Thread Standard | (1/2) - (9/16);(3/4) - (13/16) |
| Material | Carbide |
| Shank Type | Cylindrical (DIN6535-HA) |
| Function | Threading |
| EIRL | External Right-Hand;External Left-Hand;Internal Right-Hand;Internal Left-Hand |
| Is Coated | Y |
| Shank Diameter (Inch) | 0.39 in |
| Thread Form | Whitworth - 55°;BSW |
| Grade | MT7 |
| Pitch (TPI) | 12.00 TPI |
| Has Coolant | Y |
| Coolant Type | Central Bore |
| Cut Diameter (Inch) | 0.354 in |
| Country of Origin | IL |
