Carmex
MTD06038B932UNMT7
Carmex MTD06038B932UNMT7
Specifications
| Number Of Flutes | 2 |
|---|---|
| Overall Length (Inch) | 2.1 in |
| Short Description | MTD 06038 B9 32 UN MT7 |
| Thread Standard | 10 |
| Material | Carbide |
| Shank Type | Cylindrical (DIN6535-HA) |
| Chamfer Length (Metric) | 5.4 mm |
| Function | Threading |
| EIRL | Internal Right-Hand;Internal Left-Hand |
| Is Coated | Y |
| Shank Diameter (Inch) | 0.24 in |
| Chamfer Depth (Inch) | 0.47 in |
| Thread Form | UN |
| Neck Diameter (Metric) | 5.6 mm |
| Grade | MT7 |
| Pitch (TPI) | 32.00 TPI |
| Has Coolant | Y |
| Coolant Type | Offset Bore (x2) |
| Neck Diameter (Inch) | 0.22 in |
| Cut Diameter (Inch) | 0.161 in |
| Country of Origin | IL |
