Carmex
MTI0302C8045ISOMT11
Carmex MTI0302C8045ISOMT11
Specifications
| Number Of Flutes | 3 |
|---|---|
| Overall Length (Inch) | 1.5 in |
| Short Description | MTI 0302 C8 0.45 ISO MT11 |
| Thread Standard | M2.5 |
| Material | Carbide |
| Shank Type | Cylindrical (DIN6535-HA) |
| Function | Threading |
| Pitch (Metric) | 00.45 mm |
| EIRL | Internal Right-Hand;Internal Left-Hand |
| Is Coated | Y |
| Shank Diameter (Inch) | 0.12 in |
| Thread Form | ISO |
| Grade | MT11 |
| Has Coolant | N |
| Cut Diameter (Inch) | 0.077 in |
| Country of Origin | IL |
| Thread Depth | 3.5 x D1 |
