CARR LANE
CL-5A-LPB
CL-5A-LPB Locking Pin Bushings, Steel (Inch)
Specifications
| Base Item Number | LPB |
|---|---|
| Brand Name | CARR LANE |
| E | 0.62 |
| F | 0.44 |
| Short Description | Locking-Pin Bushings are equipped with a retainer spring clip on the inside diameter, for use with all types of locking/captive pins and locating screws. These precision bushings are designed to press fit in a standard reamed hole, and can be secured with a Lockscrew to positively hold the bushing in place. Also available in a threaded version, with an externally threaded shank for installation in a tapped hole. This threaded design provides less locational accuracy, but is handy when captive clamping pins are used in non-locating applications. |
| RoHS | 1144 Steel or Equivalent, Heat Treat: Carburized-hardened, Black Oxide Finish |
| B | 0.37 |
