Ceratizit

50911071

SOLID CARBIDE TORUS MILLING CUTTER

Specifications

Overall Length (Inch)2.283
Corner Radius (Inch)0.039
Corner Radius (Metric)1
Short Description3AD488-07000.0110.R04.R01000.HA.B570
Long DescriptionSOLID CARBIDE TORUS MILLING CUTTER 3AD488-07000.0110.R04.R01000.HA.B570
Neck Diameter (Metric)6.6
Neck Diameter (Inch)0.26
Product LineWNT STANDARD
Depth of Cut Maximum (Metric)11
Shank Length (Inch)1.417
Connection diameter machine side (inch)0.315
Flute Helix HandLEFT
Flute Helix Angle30
Item Width (Inches)0.71
Connection type machine sideCYL
Overall Length (mm)5.8 cm
Connection diameter machine side (mm)8
Connection diameter machine side toleranceh5
Base MaterialVHM
Item Weight (lbs)0.015
Cutting DirectionRIGHT
Item Height (Inches)0.71
Protruding Length (Metric)22
Cutting Diameter (mm)7.00 mm
Peripheral Effective Cutting Edge Count4
Rake Angle Axial5
Item Length (Inches)2.8
CoatingDIAMOND
Head Length (Inch)0.787
Shank Length (mm)36
Cutting Diameter Tolerancef8
Head Length (Metric)20
Cutting Diameter (Inch)0.276
Corner Radius Tolerance (Metric)±0.01
