Ceratizit
52305050
SOLID CARBIDE TORUS MILLING CUTTER
Specifications
| Overall Length (Inch) | 3.15 |
|---|---|
| Corner Radius (Inch) | 0.031 |
| Corner Radius (Metric) | 0.8 |
| Short Description | H.TO.5,0.30°.Z2.R0,8.HA.EL TI2000 |
| Long Description | SOLID CARBIDE TORUS MILLING CUTTER H.TO.5,0.30°.Z2.R0,8.HA.EL TI2000 |
| Neck Diameter (Metric) | 4.9 |
| Neck Diameter (Inch) | 0.193 |
| Product Line | WNT PERFORMANCE |
| Depth of Cut Maximum (Metric) | 3 |
| Shank Length (Inch) | 1.417 |
| Connection diameter machine side (inch) | 0.236 |
| Flute Helix Hand | LEFT |
| Flute Helix Angle | 30 |
| Item Width (Inches) | 0.51 |
| Connection type machine side | CYL |
| Overall Length (mm) | 8 cm |
| Connection diameter machine side (mm) | 6 |
| Connection diameter machine side tolerance | h5 |
| Base Material | VHM |
| Item Weight (lbs) | 0.09 |
| Cutting Direction | RIGHT |
| Item Height (Inches) | 0.51 |
| Cutting Diameter Tolerance (Metric) | ±0.01 |
| Protruding Length (Metric) | 44 |
| Cutting Diameter (mm) | 5.00 mm |
| Peripheral Effective Cutting Edge Count | 2 |
| Rake Angle Axial | 0 |
| Item Length (Inches) | 4.33 |
| Coating | TI2000 |
| Head Length (Inch) | 0.984 |
| Shank Length (mm) | 36 |
| Head Length (Metric) | 25 |
| Cutting Diameter (Inch) | 0.197 |
| Corner Radius Tolerance (Metric) | ±0.005 |
