Ceratizit
5259709525
SOLID CARBIDE PLASTIC CUTTER
Specifications
| Overall Length (Inch) | 3.35 |
|---|---|
| Diameter (Metric) | 9.53 |
| Diameter (Inch) | 0.38 |
| Length Of Cut (Inch) | 1.26 |
| Material | VHM |
| Overall Length (Metric) | 85 |
| Coating/Finish | DIAMOND |
| Overall Length 2 (Inch) | 3.7 |
| Cutting Direction | Right |
| Helix Angle | 7 degrees |
| Shank Length (Decimal) | 1.62 |
| Shank Length (Metric) | 41 |
| Max. Cutting Depth (Metric) | 32 |
| Connection Diameter (Decimal) | 0.38 |
| Connection Diameter (Metric) | 9.53 |
| Connection Diameter Tolerance | H6 |
| Connection Type | CYL |
| Coolant | Without IC |
| Cutting Diameter Tolerance | H11 |
| Flute Helix Hand | Right |
| Length Type | Long |
| Height (Decimal) | 0.71 |
| Length (Decimal) | 3.7 |
| Width (Decimal) | 0.71 |
| Protruding Length (Decimal) | 1.74 |
| Protruding Length (Metric) | 44 |
| Corner Chamfer Width (Decimal) | 0.01 |
| Corner Chamfer Width (Metric) | 0.1 |
| Peripheral Effective Cutting Edge Count | 8 |
| Rake Angle Axial | 0 degrees |
| Base Item Number | #5259709525 |
| Flute Helix Angle | 7 |
| Product Type | Industrial Supplies |
| Unit of Measure | Imperial |
| Unit Of Measure | Imperial |
