Ceratizit
52734020
SOLID CARBIDE TORUS MILLING CUTTER
Specifications
| Overall Length (Inch) | 3.15 |
|---|---|
| Corner Radius (Inch) | 0.02 |
| Corner Radius (Metric) | 0.5 |
| Short Description | N.TO.2,0.30°.Z2.R0,5.HA.EL80 TI1000 |
| Long Description | SOLID CARBIDE TORUS MILLING CUTTER N.TO.2,0.30°.Z2.R0,5.HA.EL80 TI1000 |
| Neck Diameter (Metric) | 1.8 |
| Neck Diameter (Inch) | 0.071 |
| Product Line | WNT STANDARD |
| Depth of Cut Maximum (Metric) | 3 |
| Shank Length (Inch) | 1.417 |
| Connection diameter machine side (inch) | 0.236 |
| Flute Helix Hand | LEFT |
| Flute Helix Angle | 30 |
| Coolant | WITHOUT IC |
| Item Width (Inches) | 0.51 |
| Connection type machine side | CYL |
| Overall Length (mm) | 8 cm |
| Connection diameter machine side (mm) | 6 |
| Connection diameter machine side tolerance | h5 |
| Base Material | VHM |
| Item Weight (lbs) | 0.069 |
| Cutting Direction | RIGHT |
| Item Height (Inches) | 0.51 |
| Cutting Diameter Tolerance (Metric) | ±0.01 |
| Protruding Length (Metric) | 44 |
| Cutting Diameter (mm) | 2.00 mm |
| Peripheral Effective Cutting Edge Count | 2 |
| Rake Angle Axial | 3 |
| Item Length (Inches) | 4.33 |
| Coating | TI1000 |
| Head Length (Inch) | 0.315 |
| Shank Length (mm) | 36 |
| Head Length (Metric) | 8 |
| Cutting Diameter (Inch) | 0.079 |
| Corner Radius Tolerance (Metric) | ±0.005 |
