Ceratizit
5615977600
TORUS CARBIDE MILLING INSERT
Specifications
| Corner Radius (Metric) | 2.5 |
|---|---|
| Corner Radius (Inch) | 0.098 |
| Inscribed Circle Diameter (Metric) | 32.00 |
| ISO Code | XOHX325025 |
| Cutting Edge Effective Length (Metric) | 28 |
| Included Angle | 90 |
| Cutting Edge Length (Metric) | 28.00 |
| Insert Length (Metric) | 28 |
| Insert Length (Inch) | 1.102 |
| Product Line | CERATIZIT_PERFORMANCE |
| Insert Thickness (Metric) | 5 |
| Insert Hand | RIGHT |
| Screw Hole Diameter (Metric) | 8.00 |
| Item Width (Inches) | 3.03 |
| Base Material | VHM |
| Item Weight (lbs) | 1.601 |
| Item Height (Inches) | 0.67 |
| Designation | 325025 |
| Inscribed Circle (Metric) | 32 |
| Item Length (Inches) | 4.45 |
| Insert Included Angle | 90.0 |
| insert interface code | XO3205253R |
