Ceratizit
5868615105
MAXIMILL SHELL BUTTON MILLING CUTTER
Specifications
| Cutting Diameter (Inch) | 1.106 |
|---|---|
| Overall Length (Inch) | 1.420 |
| Long Description | MAXIMILL SHELL BUTTON MILLING CUTTER A251.150.R.05-10-A050-175-RS-EF |
| Short Description | A251.150.R.05-10-A050-175-RS-EF |
| Product Line | CERATIZIT_PERFORMANCE |
| Depth of Cut Maximum (Metric) | 5.004 |
| Connection diameter machine side (inch) | 0.500 |
| Cutting diameter maximum (inch) | 1.500 |
| Coolant | IC_OUTSIDE |
| Item Width (Inches) | 2.24 |
| Overall Length (mm) | 3.6068 cm |
| Connection diameter machine side (mm) | 12.7 |
| Connection diameter machine side tolerance | H6 |
| Item Weight (lbs) | 0.526 |
| Item Height (Inches) | 1.97 |
| Designation | A251.150.R.05-10-A050-175-RS-EF |
| Cutting Diameter (mm) | 2.81 cm |
| Item Length (Inches) | 2.24 |
| Cutting diameter maximum (Metric) | 38.1 |
| Hub Diameter (Metric) | 36.068 |
