Ceratizit

70287902

CERMET TURNING INSERT

Specifications

Thickness (Metric)1.59
Corner Radius (Metric)0.4
MaterialCERMET
Included Angle80 degrees
Corner Radius (Inch)0.02
StyleWCGT
Thickness (Inch)0.07
Short DescriptionWCGT 020104FN-SF TCM10
Long DescriptionCERMET TURNING INSERT WCGT 020104FN-SF TCM10
GradeTCM10
Unit Of MeasureMetric
Cutting Edge Length2.710 mm
Inscribed Circle Diameter3.97 mm
Inscribed Circle Diameter (Decimal)0.16
Inscribed Circle Diameter (Metric)3.97
Cutting Edge Length (Decimal)0.11
Cutting Edge Length (Metric)2.71
Direction Of HandNeutral
Clearance Angle Major7 degrees
Chip Breaker-SF
Screw Hole Diameter (Decimal)0.09
Screw Hole Diameter (Metric)2.1
Rake Angle15 degrees
Tolerance ClassG
Product TypeIndustrial Supplies
Unit of MeasureMetric
Product LineCERATIZIT_PERFORMANCE
Insert Thickness (Metric)1.59
Insert HandNEUTRAL
Insert Rake Angle15
Item Width (Inches)1.57
Base MaterialCERMET
Item Weight (lbs)0.031
Item Height (Inches)1.57
Item Length (Inches)3.86
Insert Included Angle80
Insert Thickness (Inch)0.063
