Ceratizit
7077100800
MAXILOCK S EXTERNAL TOOLHOLDER
Specifications
| Overall Length (Metric) | 125 |
|---|---|
| Series | MaxiLock-S |
| Toolholder Style | SDACR |
| Overall Length (Inch) | 4.93 |
| Short Description | SDACR 0808 K07 DC |
| Long Description | MAXILOCK S EXTERNAL TOOLHOLDER SDACR 0808 K07 DC |
| Direction Of Hand | Right |
| Unit Of Measure | Imperial |
| Material | Steel |
| Shank Width | 0.32 Inch |
| Shank Width (Metric) | 8 |
| Shank Height (Metric) | 8 |
| Functional Width (Decimal) | 0.32 |
| Functional Width (Metric) | 8 |
| Head Length (Decimal) | 0.83 |
| Head Length (Metric) | 21 |
| Connection Type | VKT - Square |
| Coolant Entry Thread Size | M5 |
| Coolant Radial Entry Thread Size | M5 |
| Functional Height (Metric) | 8 |
| Functional Height (Decimal) | 0.32 |
| Overall Height (Metric) | 11.2 |
| Overall Height (Decimal) | 0.45 |
| Tightening Torque (Nm) | 1,2 |
| Holder Form | SDAC90 |
| Coolant | Directcooling |
| Cutting Direction | RIGHT |
| Product Type | Industrial Supplies |
| Unit of Measure | Imperial |
| Product Line | CERATIZIT_PERFORMANCE |
| Item Width (Inches) | 1.42 |
| Connection type machine side | VKT - SQUARE |
| Base Material | STEEL |
| Item Weight (lbs) | 0.228 |
| Item Height (Inches) | 1.42 |
| Item Length (Inches) | 5.51 |
| Head Length (Inch) | 0.827 |
| Overall Height (Inch) | 0.441 |
| Shank Width (Inch) | 0.315 |
| Shank Height (Inch) | 0.315 |
