IBC Member Market

Ceratizit

7501313000

CARBIDE TURNING INSERT

Specifications

Thickness (Metric)6.35
Corner Radius (Metric)0.8
MaterialCarbide
Included Angle55 degrees
Corner Radius (Inch)0.04
StyleDNMG
Thickness (Inch)0.25
Short DescriptionDNMG 150608EN-F30 CTCM120
Long DescriptionCARBIDE TURNING INSERT DNMG 150608EN-F30 CTCM120
GradeCTCM120
Unit Of MeasureImperial
Cutting Edge Length0.61 Inch
Inscribed Circle Diameter0.50 Inch
Inscribed Circle Diameter (Metric)12.7
Cutting Edge Length (Metric)15.5
Direction Of HandNeutral
Chip Breaker-F30
Screw Hole Diameter (Decimal)0.21
Screw Hole Diameter (Metric)5.16
Rake Angle15 degrees
Tolerance ClassM
Product TypeIndustrial Supplies
Unit of MeasureImperial
Product LineCERATIZIT_PERFORMANCE
Insert Thickness (Metric)6.35
Insert HandNEUTRAL
Insert Rake Angle15
Item Width (Inches)2.2
Base MaterialHM
Item Weight (lbs)0.46
Item Height (Inches)2.2
Item Length (Inches)5.43
Insert Included Angle55
Insert Thickness (Inch)0.25
