Ceratizit
7858502043
MAXILOCK S TOOLHOLDER
Specifications
| Overall Length (Metric) | 152.4 |
|---|---|
| Series | MaxiLock-S |
| Toolholder Style | SVVCN |
| Overall Length (Inch) | 6 |
| Short Description | SVVCN 20-3D |
| Long Description | MAXILOCK S TOOLHOLDER SVVCN 20-3D |
| Direction Of Hand | Neutral |
| Unit Of Measure | Imperial |
| Material | Steel |
| Shank Width | 1.25 Inch |
| Shank Width (Metric) | 31.75 |
| Shank Height (Metric) | 31.75 |
| Functional Width (Decimal) | 0.65 |
| Functional Width (Metric) | 16.46 |
| Head Length (Decimal) | 2.01 |
| Head Length (Metric) | 51.01 |
| Connection Type | VKT - Square |
| Reduced Body Diameter Length (Metric) | 51.01 |
| Reduced Body Diameter Length (Decimal) | 2.01 |
| Holder Form | SVVC72,5 |
| Cutting Direction | NEUTRAL |
| Product Type | Industrial Supplies |
| Unit of Measure | Imperial |
| Product Line | CERATIZIT_PERFORMANCE |
| Item Width (Inches) | 1.93 |
| Connection type machine side | VKT - SQUARE |
| Base Material | STEEL |
| Item Weight (lbs) | 0.086 |
| Item Height (Inches) | 5 |
| Item Length (Inches) | 1.93 |
| Head Length (Inch) | 2.008 |
| Shank Width (Inch) | 1.25 |
| Shank Height (Inch) | 1.25 |
