Ceratizit
7870141626
BORING BAR
Specifications
| Cutting Direction | LEFT |
|---|---|
| Minimum Bore Diameter (Metric) | 32.52 |
| Minimum Bore Diameter (Inch) | 1.28 |
| Direction Of Hand | Left |
| Overall Length (Metric) | 304.8 |
| Overall Length (Inch) | 12 |
| Short Description | S16T DCLNL 4N |
| Unit Of Measure | Imperial |
| Material | Steel |
| Long Description | BORING BAR S16T DCLNL 4N |
| Series | MaxiLock-D |
| Shank Height (Metric) | 22.86 |
| Connection Diameter (Decimal) | 1 |
| Connection Diameter (Metric) | 25.4 |
| Functional Width (Decimal) | 0.64 |
| Functional Width (Metric) | 16.26 |
| Connection Type | CYL |
| Reduced Body Diameter Length (Decimal) | 1.58 |
| Reduced Body Diameter Length (Metric) | 40.01 |
| Holder Form | DCLN95 |
| Product Type | Industrial Supplies |
| Unit of Measure | Imperial |
