Ceratizit
7872231222
BORING BAR
Specifications
| Cutting Direction | RIGHT |
|---|---|
| Minimum Bore Diameter (Metric) | 25.4 |
| Minimum Bore Diameter (Inch) | 1 |
| Direction Of Hand | Right |
| Overall Length (Metric) | 254 |
| Overall Length (Inch) | 10 |
| Short Description | S12S SSKCR 3 |
| Unit Of Measure | Imperial |
| Material | Steel |
| Long Description | BORING BAR S12S SSKCR 3 |
| Series | MaxiLock-S |
| Shank Height (Metric) | 18.04 |
| Connection Diameter (Decimal) | 0.75 |
| Connection Diameter (Metric) | 19.05 |
| Functional Width (Decimal) | 0.5 |
| Functional Width (Metric) | 12.7 |
| Connection Type | CYL |
| Reduced Body Diameter Length (Decimal) | 1.58 |
| Reduced Body Diameter Length (Metric) | 40.14 |
| Holder Form | SSKC75 |
| Product Type | Industrial Supplies |
| Unit of Measure | Imperial |
