Dormer.Pramet
50086
QC91PM Taper Length Drill
Specifications
| Coating/Finish | Bright |
|---|---|
| Material | HSS |
| Drill Point Angle | 135 |
| Series | QC91PM |
| Material Application Priority Usage | N - Non-ferrous metals, P - Steel and cast steel |
| UNSPSC Number | 23241614 |
| Flute Length (mm) | 11.5 cm |
| Item Width (Inches) | 6.89 |
| Hand (Cutting Direction) | Right |
| Overall Length (Decimal Inch) | 0.31 |
| Overall Length - Millimeter (OAL) | 175 |
| Overall Length (mm) | 17.5 cm |
| Item Weight (lbs) | 0.13 |
| Item Height (Inches) | 0.31 |
| Item Length (Inches) | 0.31 |
| Material Application Possible Usage | K - Cast iron, M - Stainless steel, S - High-temperature alloys |
| Length Type | Long |
| Coolant Type | External cooling supply |
| Specification | DIN 340 |
