Emuge
1943.01
Emuge 1943.010
Specifications
| Coating/Finish | Bright |
|---|---|
| Shank Type | Cylindrical |
| Diameter (Metric) | 10.0 |
| Overall Length (Metric) | 120.0 |
| Shank Size (Metric) | 10.0 |
| Material | Carbide |
| Number Of Flutes | 2.0 |
| Unit Of Measure | Metric |
| Flute Helix Angle | 30 degrees |
| Short Description | 10 mm - End Mill - Alu-Cut -Ball Nose - X-Lgth |
| Group Length | Extra Length |
| Coolant Supply Property | External |
| Shank Tolerance | h6 |
| Shank Standard | DIN 6535 |
| Flute Length (Metric) | 8.0 |
| Flute Direction | Right Hand |
| Applicable Material | Aluminum Alloys |
| Country of Origin | Germany |
| Product Type | Industrial Supplies |
| Unit of Measure | Metric |
