Emuge
AX321010.5011
Emuge AX321010.5011
Specifications
| Thread Size | 3/8"-16 |
|---|---|
| Applicable Material | Nickel Alloys & Aerospace Alloys |
| Application | Spiral Point Taps |
| Coolant Fed | No |
| Coolant Supply Property | External |
| Cutting Edge Material | HSSE |
| Flute Direction | Straight |
| Flute Helix Angle | 0° |
| Shank Tolerance | h9 |
| Short Description | 3/8-16 UNC - H10 - Plug Tap - Aero-HSF - GLT-1 |
| Tap Chamfer Form | B |
| Tap Chamfer Lght | 4 -5 P |
| Thread Length | 0.866" |
| Thread Standard | UNC |
| Thread Tolerance Class | H10 |
| Neck Length | 1.378" |
| Length Group | ANSI Length |
| Country of Origin | Germany |
