Emuge
B050C400.0966
Emuge B050C400.0966
Specifications
| Thread Standard | STI-M |
|---|---|
| Flute Direction | RH |
| Short Description | STI-M 3 - Tap - Enorm Z - GLT-1 |
| Flute Helix Angle | 45° |
| Thread Size | M 3x0.5 |
| Thread Pitch | 12:00:00 |
| Thread Tolerance Class | 6H mod |
| Thread Length | 10 mm |
| Shank Tolerance | h9 |
| Length Group | DIN Length |
| Coolant Fed | No |
| Coolant Supply Property | External |
| Tap Chamfer Form | C |
| Application | STI Taps |
| Cutting Edge Material | HSSE |
| Tap Chamfer Lght | 2 -3 P |
| Country of Origin | Germany |
| Applicable Material | Long Chipping Materials |
