Emuge
CU51A600.5046
Emuge CU51A600.5046
Specifications
| Thread Size | 7/16"-20 |
|---|---|
| Thread Standard | UNF |
| Short Description | 7/16-20 -Tap -Enorm Z/E -PM-GLT-1-2B |
| Tap Chamfer Lght | 1.5 -2 P |
| Tap Chamfer Form | E |
| Class Of Fit | 2B |
| Applicable Material | Long Chipping Materials |
| Country of Origin | Germany |
| Coolant Supply Property | External |
| Coolant Fed | No |
| Flute Direction | RH |
| Shank Tolerance | h9 |
| Flute Helix Angle | 45° |
| Length Group | DIN Length |
| Application | Spiral Flute Taps |
| Shank Standard | ANSI |
| Cutting Edge Material | HSSE-PM |
| Material Grade | HSSE-PM |
