Guhring
9033650080000
Rough-Tech 48 / GS100 U standard length, Coolant fed end mill, fine tooth, metric
Specifications
| Length Of Cut (Inch) | 0.75 |
|---|---|
| Material | Carbide |
| Overall Length (Inch) | 2.48 |
| Type | Rough-Tech 48 / GS100 U |
| Length Of Cut (Metric) | 19 |
| Shank Diameter (Inch) | 0.3150 |
| Overall Length (Metric) | 63 |
| Coating/Finish | FIREX |
| Number Of Flutes | 4 |
| Unit Of Measure | Metric |
| Coolant | With |
| Short Description | 8MM ROUGH-TECH ALU / GS100 A CARBIDE ROUGHING ENDMILL FIREX |
| Diameter | 8 mm |
| Shank Size | 8 mm |
| Overall Length | 63 mm |
| Diameter (Decimal) | 0.32 |
| Shank Size (Decimal) | 0.32 |
| Point Angle | 30 degrees |
| Shank Type | HB Weldon Flat |
| Tolerance | h10 |
| Series | 3365 |
| Diameter (Metric) | 8.0000 |
| Base Item Number | 3365 |
| Product Type | Industrial Supplies |
| Unit of Measure | Metric |
| Item Weight (lbs) | 0.0350 |
| Substrate | Carbide |
| GTIN | 04031093675659 |
| Diameter (Inch) | 0.3150 |
| Shank Diameter (mm) | 8.00 mm |
| ShankCategory | notch |
