Guhring
9037230200000
Rough-Tech 48 / GS100 U standard length end mill, fine tooth, metric
Specifications
| Length Of Cut (Inch) | 1.5 |
|---|---|
| Material | Carbide |
| Overall Length (Inch) | 4.1 |
| Type | Rough-Tech 48 / GS100 U |
| Length Of Cut (Metric) | 38 |
| Shank Diameter (Inch) | 0.7874 |
| Overall Length (Metric) | 104 |
| Coating/Finish | FIREX |
| Number Of Flutes | 4 |
| Unit Of Measure | Metric |
| Coolant | without |
| Short Description | 20MM ROUGH-TECH 48 / GS100 U CARBIDE ROUGHING ENDMILL FIREX |
| Diameter | 20 mm |
| Shank Size | 20 mm |
| Overall Length | 104 mm |
| Diameter (Decimal) | 0.79 |
| Shank Size (Decimal) | 0.79 |
| Point Angle | 30 degrees |
| Shank Type | HB Weldon Flat |
| Tolerance | h10 |
| Series | 3723 |
| Diameter (Metric) | 20.0000 |
| Base Item Number | 3723 |
| Product Type | Industrial Supplies |
| Unit of Measure | Metric |
| Item Weight (lbs) | 0.3690 |
| Substrate | Carbide |
| GTIN | 04031093388917 |
| Diameter (Inch) | 0.7874 |
| Shank Diameter (mm) | 2.00 cm |
| ShankCategory | notch |
