Guhring
9038770127000
TECH ALU TECH GA200 A
Specifications
| Length Of Cut (Inch) | 3/4 |
|---|---|
| Material | Carbide |
| Overall Length (Inch) | 4-1/2 |
| Type | Alumi-Tech / GA200 A |
| Length Of Cut (Metric) | 19.05 |
| Shank Diameter (Inch) | 0.5000 |
| Overall Length (Metric) | 114.3 |
| Coating/Finish | Super-A |
| Number Of Flutes | 3 |
| Unit Of Measure | Fractional |
| Coolant | without |
| Short Description | 1/2" ALUMI-TECH GA200A CARBIDE ENDMILL SUPER-A |
| Reach (Metric) | 70 |
| Reach (Decimal) | 2.75 |
| Reach (Fractional) | 2-3/4 |
| Diameter | 1/2 Inch |
| Shank Size | 1/2 Inch |
| Overall Length | 4-1/2 Inch |
| Diameter (Decimal) | 0.5 |
| Shank Size (Decimal) | 0.5 |
| Shank Size (Metric) | 12.7 |
| Point Angle | 45 degrees |
| Shank Type | HA Cylindrical |
| Tolerance | h10 |
| Series | 3877 |
| Base Item Number | 3877 |
| Product Type | Industrial Supplies |
| Unit of Measure | Fractional |
| Item Weight (lbs) | 1.7001 |
| Substrate | Carbide |
| GTIN | 04031093754125 |
| Diameter (Inch) | 0.5000 |
| ShankCategory | straight |
