Guhring
9055240060000
Cobalt, GU 500 DZ universal, stub length, 118° 4-facet split point, standard straight sha
Specifications
| Flute Length (Inch) | 1.1 |
|---|---|
| Type | GU 500 DZ |
| Overall Length (Inch) | 2.6 |
| Shank Size (Inch) | 0.24 |
| Material | HSCO |
| Coating/Finish | Uncoated |
| Diameter (Inch) | 0.24 |
| Number Of Flutes | 2 |
| Unit Of Measure | Metric |
| Overall Length | 66 mm |
| Point Angle | 118 degrees |
| Diameter | 6 mm |
| Flute Length | 28 mm |
| Shank Size | 6 mm |
| Shank Type | Straight |
| Point Type | Split |
| Series | 5524 |
| Drilling Depth (Decimal) | 0.75 |
| Drilling Depth (Metric) | 19 |
| Base Item Number | GU 500 DZ, Stub, HSCO, Uncoated, 118° Split Point |
| Product Type | Industrial Supplies |
| Unit of Measure | Metric |
| Drilling Depth | Stub length |
| Order Code | 6.0000 |
| Coolant | no |
| d2 (in) | 0.2362 |
| ItemWeight | 0.0054 |
| Substrate | HSCO |
| PackWeight | 0.0120 |
| tmax (in) | 0.7480 |
| L1 (inch) | 2.5980 |
| L2 (mm) | 28.0000 |
| tmax (mm) | 19.0000 |
| ShankCategory | straight |
| Substrate Category | Cobalt |
| d1 (in) | 0.2362 |
| L1 (mm) | 66.0000 |
| D2 (mm) | 6.0000 |
| L 2(inch) | 1.1020 |
| D1 (mm) | 6.0000 |
