Guhring
9251380040100
Insert for internal grooving, full radius slots
Specifications
| Overall Length (Metric) | 30 |
|---|---|
| Material | Carbide |
| Cutting Direction | Right Hand |
| Type | GE 104 |
| Coating/Finish | Uncoated |
| Series Description | Insert for internal grooving, full radius slots |
| Minimum Bore Diameter (Decimal) | 0.16 |
| Minimum Bore Diameter (Metric) | 4 |
| Corner Reach (Metric) | 4 |
| Point Radius (Decimal) | 0.023 |
| Point Radius (Metric) | 0.58 |
| Base Item Number | 9251380040100 |
| Max. Depth Of Cut (Decimal) | 0.04 |
| Max. Depth Of Cut (Metric) | 1 |
| Maximum Depth Of Cut (Inch) | 0.04 |
| Maximum Depth Of Cut (Metric) | 1 |
| Product Type | Industrial Supplies |
| l3 (mm) | 3.7000 |
| D3 (mm) | 0.5800 |
| Substrate | Carbide |
| tmax (in) | 0.0390 |
| L2 (mm) | 1.7000 |
| tmax (mm) | 1.0000 |
| d1 (in) | 0.1580 |
| D2 (mm) | 30.0000 |
| D1 (mm) | 4.0000 |
