Guhring

9251500040060

Insert for internal threading, partial profile - metric standard threads

Specifications

Overall Length (Metric)30
MaterialCarbide
Cutting DirectionRight Hand
TypeGG 104
Coating/Finishnano-A
Series DescriptionInsert for internal threading, partial profile - metric standard threads
Minimum Bore Diameter (Decimal)0.1
Minimum Bore Diameter (Metric)2.5
Corner Chamfer (Metric)0.05
Corner Radius (Metric)0.5
Corner Reach (Metric)4
Base Item Number9251500040060
Max. Depth Of Cut (Decimal)0.01
Max. Depth Of Cut (Metric)0.3
Maximum Depth Of Cut (Inch)0.01
Maximum Depth Of Cut (Metric)0.3
Product TypeIndustrial Supplies
l3 (mm)2.2000
SubstrateCarbide
tmax (in)0.0120
L2 (mm)1.9500
L5 (mm)0.3000
tmax (mm)0.3000
d1 (in)0.0980
D2 (mm)30.0000
D1 (mm)2.5000
