Guhring
9251560040050
Insert for internal threading, partial profile - metric fine threads
Specifications
| Overall Length (Metric) | 30 |
|---|---|
| Material | Carbide |
| Cutting Direction | Right Hand |
| Type | GG 104 |
| Coating/Finish | TiN |
| Series Description | Insert for internal threading, partial profile - metric fine threads |
| Minimum Bore Diameter (Decimal) | 0.14 |
| Minimum Bore Diameter (Metric) | 3.5 |
| Corner Chamfer (Metric) | 0.03 |
| Corner Radius (Metric) | 0.35-0.50 |
| Corner Reach (Metric) | 4 |
| Base Item Number | 9251560040050 |
| Max. Depth Of Cut (Decimal) | 0.01 |
| Max. Depth Of Cut (Metric) | 0.3 |
| Maximum Depth Of Cut (Inch) | 0.01 |
| Maximum Depth Of Cut (Metric) | 0.3 |
| Product Type | Industrial Supplies |
| l3 (mm) | 3.2000 |
| Substrate | Carbide |
| tmax (in) | 0.0120 |
| L2 (mm) | 1.9500 |
| L5 (mm) | 0.3500 |
| tmax (mm) | 0.3000 |
| d1 (in) | 0.1380 |
| D2 (mm) | 30.0000 |
| D1 (mm) | 3.5000 |
