Guhring

9251590040030

Insert for internal threading, partial profile - metric fine threads

Specifications

Overall Length (Metric)30
MaterialCarbide
Cutting DirectionLeft Hand
TypeGG 104
Coating/Finishnano-A
Series DescriptionInsert for internal threading, partial profile - metric fine threads
Minimum Bore Diameter (Decimal)0.07
Minimum Bore Diameter (Metric)1.7
Corner Chamfer (Metric)0.02
Corner Radius (Metric)0.20-0.30
Corner Reach (Metric)4
Base Item Number9251590040030
Max. Depth Of Cut (Decimal)0.01
Max. Depth Of Cut (Metric)0.2
Maximum Depth Of Cut (Inch)0.01
Maximum Depth Of Cut (Metric)0.2
Product TypeIndustrial Supplies
l3 (mm)1.5500
SubstrateCarbide
tmax (in)0.0080
L2 (mm)1.9500
L5 (mm)0.2000
tmax (mm)0.2000
d1 (in)0.0670
D2 (mm)30.0000
D1 (mm)1.7000
