Guhring
9257660060190
Insert for internal threading, partial profile - metric standard threads
Specifications
| Overall Length (Metric) | 57 |
|---|---|
| Material | Carbide |
| Cutting Direction | Right Hand |
| Type | GG 106 |
| Coating/Finish | nano-A |
| Series Description | Insert for internal threading, partial profile - metric standard threads |
| Minimum Bore Diameter (Decimal) | 0.4 |
| Minimum Bore Diameter (Metric) | 10.2 |
| Corner Chamfer (Metric) | 0.21 |
| Corner Radius (Metric) | 1.75 |
| Corner Reach (Metric) | 6 |
| Base Item Number | 9257660060190 |
| Max. Depth Of Cut (Decimal) | 0.04 |
| Max. Depth Of Cut (Metric) | 1 |
| Maximum Depth Of Cut (Inch) | 0.04 |
| Maximum Depth Of Cut (Metric) | 1 |
| Product Type | Industrial Supplies |
| l3 (mm) | 5.9500 |
| Substrate | Carbide |
| tmax (in) | 0.0390 |
| L2 (mm) | 2.9500 |
| L5 (mm) | 1.0000 |
| tmax (mm) | 1.0000 |
| d1 (in) | 0.4020 |
| D2 (mm) | 57.0000 |
| D1 (mm) | 10.2000 |
