Guhring
9258250060040
Insert for internal threading, partial profile - trapezoidal thread
Specifications
| Overall Length (Metric) | 57 |
|---|---|
| Material | Carbide |
| Cutting Direction | Left Hand |
| Type | GG 106 |
| Coating/Finish | TiN |
| Series Description | Insert for internal threading, partial profile - trapezoidal thread |
| Minimum Bore Diameter (Decimal) | 0.32 |
| Minimum Bore Diameter (Metric) | 8 |
| Corner Radius (Metric) | 2 |
| Corner Reach (Metric) | 6 |
| Base Item Number | 9258250060040 |
| Max. Depth Of Cut (Decimal) | 0.05 |
| Max. Depth Of Cut (Metric) | 1.25 |
| Maximum Depth Of Cut (Inch) | 0.05 |
| Maximum Depth Of Cut (Metric) | 1.25 |
| Product Type | Industrial Supplies |
| l3 (mm) | 5.9500 |
| Substrate | Carbide |
| tmax (in) | 0.0510 |
| L2 (mm) | 2.9500 |
| L5 (mm) | 0.7500 |
| tmax (mm) | 1.2500 |
| d1 (in) | 0.3150 |
| D2 (mm) | 57.0000 |
| D1 (mm) | 8.0000 |
