Harvey Tool
22812
HT - 22812
Specifications
| Overall Length (Inch) | 2 |
|---|---|
| Diameter (Inch) | 3/16 |
| Length Of Cut (Inch) | 0.13 |
| Coating/Finish | UN |
| Neck Diameter (Decimal) | 0.15 |
| Short Description | 0.1875" (3/16) Cutter DIA x 0.5000" (1/2) Neck Length x 220° Wrap Angle - 4 FL |
| Long Description | 0.1875" (3/16) Cutter DIA x 0.5000" (1/2) Neck Length x 220° Carbide Undercutting End Mill, 4 Flutes |
| Shank Size | 3/16 Inch |
| Shank Size (Decimal) | 0.19 |
| Number Of Flutes | 4 |
| Neck Length (Decimal) | 0.5 |
| Neck Length (Fraction) | 1/2 |
| Metric | No |
| Overall Reach (Decimal) | 0.63 |
| Radius (Decimal) | 0.1 |
| Radius (Fraction) | 3/32 |
| Wrap Angle | 220 |
| Base Item Number | 22812 |
| Neck Diameter (Inch) | 0.15 |
| Product Type | Industrial Supplies |
| Shank Diameter | 0.1875" (3/16) |
| Weight | 0.024 |
| Overall Length | 2.0000" (2) |
| Cutter Diameter | 0.1875" (3/16) |
| Profile | Spherical |
| Neck Diameter | 0.1410" |
| Neck Length | 0.5000" (1/2) |
| Length of Cut | 0.1260" |
| Radius | 0.0937" (3/32) |
