Harvey Tool
24910-C4
HT - 24910-C4
Specifications
| Coating/Finish | C4 |
|---|---|
| Overall Length (Inch) | 4 |
| Length Of Cut (Inch) | 15/64 |
| Shank Size (Inch) | 1/4 |
| Number Of Flutes | 2 |
| Neck Diameter (Decimal) | 0.21 |
| Shank Diameter | 0.2500" (1/4) |
| Overall Length | 4 Inch |
| Length of Cut | 15/64 Inch |
| Shank Size | 1/4 Inch |
| Metric | No |
| Cutter Diameter (Decimal) | 0.16 |
| Cutter Diameter (Fraction) | 5/32 |
| LOC Multiple | 1.5x |
| Minor Diameter (Decimal) | 0.15 |
| Neck Angle | 2 |
| Neck Length (Decimal) | 0.16 |
| Neck Length (Fraction) | 5/32 |
| Overall Reach (Decimal) | 1.5 |
| Overall Reach (Fraction) | 1-1/2 |
| Tapered Reach (Decimal) | 1.25 |
| Tapered Reach (Fraction) | 1-1/4 |
| Base Item Number | 24910-C4 |
| Neck Diameter (Inch) | 0.21 |
| Product Type | Industrial Supplies |
| Weight | 0.084 |
| Cutter Diameter | 0.1560" (5/32) |
| Profile | Ball |
| Neck Diameter | 0.2040" |
| Neck Length | 0.1560" (5/32) |
