Harvey Tool
31039-C6
HT - 31039-C6
Specifications
| Length Of Cut (Inch) | 1/32 |
|---|---|
| Corner Radius (Inch) | 0.005 |
| Overall Length (Inch) | 2-1/2 |
| Coating/Finish | C6 |
| Number Of Flutes | 2 |
| Corner Radius | 0.0050" |
| Neck Diameter | 0.04 Inch |
| Diameter | 0.04 |
| Shank Size | 1/4 Inch |
| Overall Length | 2-1/2 Inch |
| Shank Size (Decimal) | 0.25 |
| Metric | No |
| Overall Reach (Decimal) | 0.32 |
| Overall Reach (Fraction) | 5/16 |
| Reach Multiple | 8x |
| Length of Cut | 1/32 Inch |
| LOC Multiple | 0.8x |
| Base Item Number | 31039-C6 |
| Product Type | Industrial Supplies |
| Weight | 0.046 |
| Shank Diameter | 0.2500" (1/4) |
| Cutter Diameter | 0.0390" (1 mm) |
| Profile | Corner Radius |
