Harvey Tool
65728
HT - 65728
Specifications
| Overall Length (Inch) | 2 |
|---|---|
| Length Of Cut (Inch) | 0.0029 |
| Coating/Finish | UN |
| Neck Diameter (Decimal) | 0.03 |
| Short Description | 0.0280" (.7 mm) Head DIA x 0.1250" (1/8) Neck Length x 45° per side - 3 FL |
| Long Description | 0.0280" (.7 mm) Head DIA x 0.1250" (1/8) Neck Length x 45° per side Carbide Back Deburring Mill, 3 Flutes |
| Shank Size | 1/8 Inch |
| Included Angle | 90 Degrees |
| Shank Size (Decimal) | 0.13 |
| Number Of Flutes | 3 |
| Neck Length (Decimal) | 0.13 |
| Neck Length (Fraction) | 1/8 |
| Angle per Side | 45 Degrees |
| Metric | No |
| Chamfer Center Diameter | 0.03 |
| Chamfer Center Length (Decimal) | 0.02 |
| End Length (Decimal) | 0.02 |
| Head Diameter (Decimal) | 0.03 |
| Head Diameter (Metric) | 0.7 |
| Base Item Number | 65728 |
| Neck Diameter (Inch) | 0.03 |
| Product Type | Industrial Supplies |
| Shank Diameter | 0.1250" (1/8) |
| Weight | 0.013 |
| Overall Length | 2.0000" (2) |
| Profile | Back Chamfer |
| Head Diameter | 0.0280" (.7 mm) |
| Neck Diameter | 0.0210" |
| Neck Length | 0.1250" (1/8) |
| Length of Cut | 0.0029" |
