Harvey Tool
697831
Miniature End Mill - Ball - Deburring End Mill
Specifications
| Long Description | 0.0310" (1/32) Cutter DIA x 0.0470" (3/64) Length of Cut Carbide Deburring Ball End Mill, 6 RH Teeth, 5 LH Teeth |
|---|---|
| Short Description | 6 RH Teeth, 5 LH Teeth - 0.0310" (1/32) Cutter DIA x 0.0470" (3/64) LOC |
| Shank Diameter | 0.1250" (1/8) |
| LOC Multiple | (1.5x) |
| Weight | 0.031 |
| Overall Length | 2.5000" (2-1/2) |
| Cutter Diameter | 0.0310" (1/32) |
| Profile | Ball |
| Metric | N |
| Coating | UN |
| Length of Cut | 0.0470" (3/64) |
| Center Cutting | false |
| Right Hand Teeth | 6 |
| Left Hand Teeth | 5 |
