Harvey Tool
806849
HT - 806849
Specifications
| Overall Length (Inch) | 3 |
|---|---|
| Diameter (Inch) | 0.5 |
| Length Of Cut (Inch) | 1/4 |
| Coating/Finish | UN |
| Neck Diameter (Decimal) | 0.27 |
| Short Description | 0.4950" Cutter DIA x 50° included - 3 FL |
| Long Description | 0.4950" Cutter DIA x 50° included Carbide Sight Groove Dovetail Cutter, 3 Flutes |
| Shank Size | 1/2 Inch |
| Included Angle | 50 Degrees |
| Number Of Flutes | 3 |
| Neck Radius (Decimal) | 0.005 |
| Angle per Side | 25 Degrees |
| Metric | N |
| Base Item Number | 806849 |
| Neck Diameter (Inch) | 0.27 |
| Product Type | Industrial Supplies |
| Shank Diameter | 0.5000" (1/2) |
| Weight | 0.278 |
| Overall Length | 3.0000" (3) |
| Cutter Diameter | 0.4950" |
| Profile | Pointed |
| Neck Diameter | 0.2610" |
| Length of Cut | 0.2500" (1/4) |
| Center Cutting | false |
| Neck Radius | 0.0050" |
