Harvey Tool
814331
HT - 814331
Specifications
| Shank Size (Inch) | 1/8 |
|---|---|
| Overall Length (Inch) | 2-1/2 |
| Length Of Cut (Inch) | 3/64 |
| Number Of Flutes | 3 |
| Coating/Finish | UN |
| Double Ended | N |
| Diameter (Inch) | 1/32 |
| Neck Diameter (Decimal) | 0.03 |
| Shank Diameter | 0.1250" (1/8) |
| Overall Length | 2.5000" (2-1/2) |
| Center Cutting | No |
| Metric | No |
| LOC Multiple | 1.5x |
| Chip Breaker | No |
| Coolant Through | No |
| Overall Reach (Decimal) | 0.13 |
| Overall Reach (Fraction) | 1/8 |
| Reach Multiple | 4x |
| Weldon Flat | No |
| Length of Cut | 0.0470" (3/64) |
| Base Item Number | 814331 |
| Neck Diameter (Inch) | 0.03 |
| Product Type | Industrial Supplies |
| Weight | 0.015 |
| Cutter Diameter | 0.0310" (1/32) |
| Profile | Square |
| Neck Diameter | 0.0300" |
