Harvey Tool
859240-C8
HT - 859240-C8
Specifications
| Overall Length (Inch) | 3-1/2 |
|---|---|
| Diameter (Inch) | 5/8 |
| Coating/Finish | C8 |
| Neck Diameter (Decimal) | 0.38 |
| Short Description | 0.6250" (5/8) Cutter DIA x 0.2075" Width x 0.5000" (1/2) Neck Length - 90° Included Angle - 6 FL - TiB2 Coated |
| Long Description | 0.6250" (5/8) Cutter DIA x 0.2075" Width x 0.5000" (1/2) Neck Length Carbide Picatinny Attachment Cutters, 6 Flutes, TiB2 Coated |
| Shank Size | 5/8 Inch |
| Included Angle | 90 Degrees |
| Shank Size (Decimal) | 0.63 |
| Number Of Flutes | 6 |
| Neck Diameter (Fraction) | 3/8 |
| Neck Length (Decimal) | 0.5 |
| Neck Length (Fraction) | 1/2 |
| Angle per Side | 45 Degrees |
| Metric | No |
| Cutter Width | 0.21 Inch |
| Tip Flat (Decimal) | 0.021 |
| Coolant Through | No |
| Base Item Number | 859240-C8 |
| Neck Diameter (Inch) | 0.38 |
| Product Type | Industrial Supplies |
| Shank Diameter | 0.6250" (5/8) |
| Weight | 0.485 |
| Double Ended | N |
| Overall Length | 3.5000" (3-1/2) |
| Cutter Diameter | 0.6250" (5/8) |
| Profile | Attachment Form |
| Neck Diameter | 0.3750" (3/8) |
| Neck Length | 0.5000" (1/2) |
| Center Cutting | false |
