Harvey Tool
955204-C3
HT - 955204-C3
Specifications
| Overall Length (Inch) | 1-1/2 |
|---|---|
| Coating/Finish | C3 |
| Number Of Flutes | 4 |
| Short Description | 0.0680" Max Opening Width x 0.1250" (1/8) Shank DIA x 90° Included - 4 FL - AlTiN Coated |
| Radius (Decimal) | 0.006 |
| Shank Size | 1/8 Inch |
| Overall Length | 1.5000" (1-1/2) |
| Shank Size (Decimal) | 0.13 |
| Long Description | 0.0680" Max Opening Width x 0.1250" (1/8) Shank DIA x 90° Included Carbide Plate Chamfer, 4 Flutes, AlTiN Coated |
| Chamfer Length | 0.02 Inch |
| Metric | No |
| Included Angle | 90 Degrees |
| End Length (Decimal) | 0.04 |
| End to Center (Decimal) | 0.08 |
| Max Opening Width (Decimal) | 0.07 Inch |
| Min Opening Width (Decimal) | 0.04 Inch |
| Minor Diameter (Decimal) | 0.1 |
| Angle per Side | 45 Degrees |
| Base Item Number | 955204-C3 |
| Product Type | Industrial Supplies |
| Weight | 0.009 |
| Shank Diameter | 0.1250" (1/8) |
| Profile | Plate Chamfer |
| Radius | 0.0060" |
