Harvey Tool
998736-C6
HT - 998736-C6
Specifications
| Coating/Finish | C6 |
|---|---|
| Overall Length (Inch) | 3 |
| Length Of Cut (Inch) | 1/16 |
| Type | I |
| Shank Size (Inch) | 1/4 |
| Number Of Flutes | 2 |
| Neck Diameter (Decimal) | 0.10 |
| Shank Diameter | 0.2500" (1/4) |
| Overall Length | 3 Inch |
| Length of Cut | 1/16 Inch |
| Shank Size | 1/4 Inch |
| Metric | No |
| Cutter Diameter (Decimal) | 0.08 |
| Cutter Diameter (Fraction) | 5/64 |
| LOC Multiple | 0.8x |
| Neck Angle | 0.5 |
| Overall Reach (Decimal) | 1.49 |
| Tapered Reach (Decimal) | 1 |
| Tapered Reach (Fraction) | 1 |
| Base Item Number | 998736-C6 |
| Neck Diameter (Inch) | 0.1 |
| Product Type | Industrial Supplies |
| Weight | 0.049 |
| Cutter Diameter | 0.0780" (5/64) |
| Profile | Ball |
| Neck Diameter | 0.0940" (2.4 mm) |
