Harvey Tool
RSB0410
HT - RSB0410
Specifications
| Number Of Flutes | 4 |
|---|---|
| Reamer Diameter (Inch) | 0.05 |
| Overall Length (Inch) | 2 |
| Shank Size (Inch) | 1/8 |
| Coating/Finish | UN |
| Short Description | 0.0410" Reamer DIA x 0.2810" (9/32) Margin Length - 4 FL |
| Long Description | 0.0410" Reamer DIA x 0.2810" (9/32) Margin Length Carbide Reamer, 4 Flutes |
| Angle per Side | 45 Degrees |
| Chamfer Length (Decimal) | 0.0047 |
| Included Angle | 90 Degrees |
| LOC Multiple | 7x |
| Margin Length (Decimal) | 0.29 |
| Margin Length (Fraction) | 9/32 |
| Neck Diameter (Decimal) | 0.04 |
| Overall Reach (Decimal) | 0.5 |
| Overall Reach (Fraction) | 1/2 |
| Reach Multiple | 12x |
| Base Item Number | RSB0410 |
| Neck Diameter (Inch) | 0.04 |
| Product Type | Industrial Supplies |
| Shank Diameter | 0.1250" (1/8) |
| Weight | 0.009 |
| Overall Length | 2.0000" (2) |
| Profile | Reamer |
| Metric | N |
| Neck Diameter | 0.0395" |
| Chamfer Length | 0.0047" |
